Capacitance and ESR Meter (VEL28E)

Features

• ESR measurement range 0 to 40 Ohm
• ESR resolution as low as 0.01 Ohm
• capacitance range 1µF…22mF (22,000µF)
• can also be used for low-Ohms resistance checking
• built-in protection circuitry means risk of damage to the
  unit due to residual charge is greatly reduced
• integrated controlled discharge circuitry reduces the need
  for the user to manually discharge capacitors before test
• use in or out of circuit for ESR measurement
• automatic and manual power-off
• with audible alerts

Specifications

• Specification Summary at 20°C (68°F) unless otherwise specified
• peak test current into S/C: ±20mA ~ ±25mA
• peak test voltage across O/C: ±2.5V ~ ±3.0V
• capacitance measurement range: 1µF ~ 22,000µF
• capacitance accuracy: ±4%±0.2µF
• ESR:
  • measurement range: 0 Ohm ~ 40 Ohm
  • resolution (ESR
  • resolution (ESR>2 Ohm): 0.1 Ohm ~ 0.2Ohm
  • accuracy (ESR
  • accuracy (ESR>2 Ohm): ±1.5% ±0.2O
• abuse voltage: C<10µF ±275V; C>10µF ±50V
• auto-discharge voltage limit: ±50V
• battery:
  • type: MN21/GP23A 12V Alkaline
  • voltage range: 8.5V ~ 12V
  • voltage warning threshold: 8.5V
• inactivity power-down period: 30s
• dimensions: 103x70x20mm (4.1 x 2.8 x 0.8)
• operating temperature range: 10°C ~ 40°C (50F ~ 104F)
• Weight per product (nett): 0.098kg (3.5oz)
