Solid State Relay Switch (KIT94S)

Warning: This kit requires high voltage input and should only be installed by a qualified technician. The kit should be fitted into a suitable enclosure not to expose high voltage components.

A Solid State Relay Switch kit designed to control (ON/OFF) a single phase high power circuit from a low power DC drive. AC lamp drive, Micro-controller interface etc. Max load 300W.

Supply 230 VAC
Triac and opto-coupler based design
Trigger voltage 2 to 5 VDC (TTL) @ 10 mA
Input isolated with use of opto-coupler
Power Battery Terminal (PBT) for input mains supply and load connection
Berg connector for connecting input trigger signal
Heatsink for TRIAC
Four mounting holes of 3.2 mm each
PCB dimensions 65 mm x 28 mm
