Relay, 8-pin, 12VAC 10A DPDT (RLY024)

Standard 8-pin octal style 10A relay with double-pole double-throw contacts.
Coil voltage 12V AC.
Contacts rated 10A at 24VDC 10A, 7.5A at 220VAC, 0.3A at 220VDC 0.3A
Overall size 35 x 35 x 55mm plus 14.6mm overall octal base depth.
Socket available see Order Code RLY011.

Specification:
Coil Rated Voltage: 12V AC
Current Power Consumption: 3VA
Must Operate Voltage: 9.6V max.
Must Release Voltage: 3.6V min.
Max. Coil Voltage: 13.2V DC
Power Consumption: 2W
Contact Resistance: 0.1 ohms max.
Operate Time: 20ms max.
Release Time: 20ms max.
Contact Material: Silver alloy

Pinouts viewed from bottom....
